Inputs

• 1 HDMI: On a female HDMI connector

• 1 USB-C: On USB type–C female connector

Outputs

• 4 HDMI: On female HDMI connectors

• 1 HDMI local: On a female HDMI connector

Ports

• 1 1000BaseT Ethernet: On an RJ–45 female connector for LAN connection & extension

• Analog Audio: On a 5–pin R–L analog audio output

• IO: On 2–pin terminal block connectors

• 2 RS-232: On 3–pin terminal block connectors

Video

• Max Bandwidth: 18Gbps (6Gbps per graphic channel)

• Max Resolution: 4K@60Hz 4:4:4 24bpp resolution

• Content Protection: HDCP 2.3

• Compliance: HDMI 2.0b

Security

• Web-UI Communication: HTTPS

• User Access: Multiple roles and credentials

• IT LAN Authentication: 802.1x

• Penetration Protection Certification: : OWASP–10

Power

• Source: 20 VDC

• Max Consumption: 76W

• Max Power Providing Per HDMI Port: 2.5W (5V@0.5A)

Environmental Conditions

• Operating Temperature: 0° to +40°C (32° to 104°F)

• Storage Temperature: –40° to +70°C (–40° to 158°F)

• Humidity: 10% to 90%, RHL non–condensing

Regulatory Compliance (Standards Compliance)

• Safety: CE, FCC, UL

• Environmental: RoHs, WEEE

Enclosure

• Type: Half–U 19"

• Type: Aluminum

• Cooling: Low noise fan

Accessories

• Power Adapter: Included

Product Dimensions

• 21.46cm x 16.30cm x 4.36cm (8.45" x 6.42" x 1.72" ) W, D, H

Product Weight

• 0.8kg (1.8lbs) approx.
